22
Curtis 1244 Manual, Rev. E
Table 2 MODE SELECTION
MODE MODE
OPERATING MODE SELECT SELECT
SWITCH 1 SWITCH 2
MultiMode™ 1 OPEN OPEN
MultiMode™ 2 CLOSED OPEN
MultiMode™ 3 OPEN CLOSED
MultiMode™ 4 CLOSED CLOSED
2 — INSTALLATION & WIRING:
Switches, etc.
Circuitry Protection Devices
To protect the control circuitry from accidental shorts, a low current fuse (ap-
propriate for the maximum current draw) should be connected in series with
the battery feed to the keyswitch. Additionally, a high current fuse should be
wired in series with the main contactor to protect the motor, controller, and
batteries from accidental shorts in the power system. e appropriate fuse for
each application should be selected with the help of a reputable fuse manu-
facturer or dealer. e standard wiring diagram (Figure 3, page 8) shows the
recommended location for each fuse.
Mode Select Switch Operation
e two mode select switches (Mode Select 1 and Mode Select 2) together
define the four operating modes. e switch combinations are shown in Table 2.
Wiring for the mode select switches is shown in the standard wiring diagram
(Figure 3, page 8).
