3.2 Connections

PC
serial device
Serial
standard cable
PC
USB device
USB
standard cable
Power
supply
Power supply
cable
(optional)
ATTENTION: In some using conditions, we recommend the installation of a ferrite core on the power supply cable.
NOTE: If serial and USB connectors are inserted, communication port is USB.
21
