Custom Audio Electronics K-80 - Paper Specs for Black Mark Sensor

7.5 
Paper with black mark on the thermal side
The following image shows the placement of the black mark on the thermal side of the paper. For more information about
the use of paper with black mark see Chapter 10.
ATTENTION: Requires the assembly of the black mark sensor kit (optional, see chapter 9).

7.5
Position of the black mark sensor: right
40.5
Position of the black mark sensor: central
73.5
Position of the black mark sensor: left
PAPER WIDTH 76, 80 mm
THERMAL SIDE
5÷10
min 70
min 9
54
