7.3
Device dimensions
Model A
Length
258 mm
Height
103.5 mm
Width
135 mm
Weight
1250 g
NOTE:
millimetres.
38.3
101.75
103.5
7.6
180
258
94.6
23.3
64
78
30
50
45.6
54
30
135
148
91.5
51
50
52
