Paper with black mark on the non-thermal side
The following image shows the placement of the black mark on the non-thermal side of the paper. For more information
about the use of paper with black mark see Chapter 10.
ATTENTION: Requires the assembly of the black mark sensor kit (optional, see chapter 9).
7.5
Position of the black mark sensor: left
40.5
Position of the black mark sensor: central
73.5
Position of the black mark sensor: right
PAPER WIDTH 76, 80 mm
NON-THERMAL SIDE
5÷10
min 70
min 9
55
