1. INSTALLATION AND USE
KPM216H
121-
ATTENTION
Remove the cover before
pulling up the cutter.
Extract the cover unit pulling from the bottom to the outside and then lifting up to release
the two slots (see fig.1.18).
4) Pulling up the cutter as shown in the fig. 1.19; remove any pieces of paper.
(Fig.1.18)
(Fig.1.19)
