Custom Audio Electronics KPM 216 H - Page 5

KPM216H
5
6
8
7
1
2
4
3
KPM216H-U
model
KPM216H-P
model
C. KPM216H – Under view
KPM216H-U model
1- Serial connector
2- USB connector
3- Power supply connector
4- Power supply fuse
KPM216H-P model
5- Serial connector
6- Centronics connector
7- Power supply fuse
8- Power supply connector
