Page #12 background imageLoading...
Page #12 background image
Technical Reference Manual
Page 12 of 38
PT-3000
1.3 Connector’s Description
1.3.1 J1: Power Connector
Pin Signal
1+5V
2+5V
3GND
4GND
5GND
6+12V
1.3.2 J2: Invert Power Connector
Pin Signal
1+12V
2GND
3 LCD ADJ.
4+5V
5+5V
1.3.3 J3: LCD Bright Connector
(
Default: 2-3 short
)
Pin Signal
1+5V
2 LCD ADJ.
3GND
4N.C.
1.3.4 JP15: LAN LED Connector
Pin Signal
1LED +
2LED -
3LED +
4LED -
5LED +
6LED -
1.3.5 JP17: FAN Power Connector
Pin Signal
1+5V
2GND
3+12V
