Technical Reference Manual
Page 7 of 38
PT-3000
1 CHAPTER 1 - HARDWARE DESCRIPTION
1.1 Technical Specification
• CPU: Intel Pentium P54C / P55C, MMX 233 MHz
Option: AMD K5/ K6, Cyrix 6x86 & IDT C6.
• Chipset: SiS 5582.
• BIOS: AWARD 128KB Flash ROM includes System
& Video BIOS, Ethernet Boot ROM, SSD Driver and
support Plug and play.
• Cache Memory: On-board 512KB-pipelined burst SRAM.
• RAM: 2 x 168-pin SIMM upgradable to 128MB.
• EIDE Interface: Support two HDD’s (3.5” & 2.5” each).
• FDD Interface : Support two FDD’s (1.44MB).
• Parallel Port: 1 port, support SPP/EPP/ECP parallel mode.
• Serial Port: 4 RS232C ports, supports
2 x 9-pin D-type (COM1, 2)
1 x 8-pin RJ45 type (COM3) and
1 x internal port used for touch panel (COM4).
• Watchdog Timer: Generates a system reset, timing & temperature
Intervals are software programmable.
• Keyboard: Support one PS/2 type keyboard.
• Mouse: Support one PS/2 type mouse.
• USB Interface : Support two USB devices with fuse protection.
Compliant with USB specs Rev 1.0
• Display Interface: 12.1” LCD single / double tube option and CRT
(PCI SVGA) display. Simultaneously supports CRT and
flat panel (EL, LCD and Gas Plasma) display.
Resolution: Support non-interlaced CRT & LCD display up
to 1024 x 768 @ 256 colors with onboard 1MB video
memory. Expandable to 2 MB.
• Cash Drawer: 1 x RJ11 connector, support two cash drawers.
Drive Voltage: +24V DC
Drive Current: 0.8A at maximum (within 510 ms)
• Ethernet: 1 x RJ45 connector supports 10/100 Base-T,
NE2000 compatible.
• Touch Panel: Elo TouchSystem, five-wire resistive sensor.
• Disk-On-Chip: Supports Disk-On-Chip 2000 serials,
Upgradable to 72 MB.
• DC Power: Support +24VDC/ 3A output for printer Interface.
• Customer Display: Support +12VDC, 2 x 20 character display
Interface through COM3 serial port.
• MSR Interface: Supports 1 / 2 / 3 track reader.
• Power Supply: Adapter Input: 110 ~ 230 VAC, 50/ 60 Hz
Adapter Output: +5V/10A, +12V/2A, +24V/3A
Total wattage: 146 W
