1.3.6 J7: DOC-2000 Controller Programming Connector
Pin Signal
1TDO
2TCK
3TMS
4TDI
5GND
6+ 5V
1.3.7 J8: Power LED Connector
Pin Signal
1LED +
2LED -
1.3.8 JP3: Hard Disk Drive LED
Pin Signal
1LED +
2LED -
1.3.9 JP4: Slave IDE Connector (44 pin)
Pin Signal Pin Signal
1IDE RESET2 GND
3DATA 74DATA 8
5DATA 66DATA 9
7DATA 58DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 SIGNAL GND 20 N/C
21 HDD 0 22 GND
23 IO WRITE 24 GND
25 IO READ 26 GND
27 HD READY 28 N/C
29 HDACK 0 30 GND
31 IRQ14 32 N/C
33 ADDR 1 34 N/C
35 ADDR 0 36 ADDR 2
37
HARD DISK
SELECT 0
38
HARD DISK
SELECT 1
39 IDE ACTIVE 40 GND
41 VCC 42 VCC
43 GND 44 N/C
44
43
2
1
