DMA n assigned to: When the resources are controlled manually, assign each system
DMA channel as one of the following types, depending on the type of device using the
interrupt:
• Legacy ISA Devices compliant with the original PC AT bus specification, requiring
a specific DMA channel.
• PCI/ISA PnP devices complaints with the plug and play standard, whether
designed for PCI or ISA bus architecture.
2.1.6 Integrated Peripherals Setup Menu
ROM PCI/ISA BIOS <2A5IIAKA>
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC
.
Internal PCI/IDE: Both
IDE Primary Master PIO: Auto
IDE Primary Slave PIO: Auto
IDE Secondary Master PIO: Auto
IDE Secondary Slave PIO: Auto
Primary Master Ultra DMA: Auto
Primary Slave Ultra DMA: Auto
Secondary Master Ultra DMA: Auto
Secondary Slave Ultra DMA: Auto
IDE Burst Mode : Enable
IDE Data Port Post Write: Enable
IDE HDD Block Mode: Enable
Onboard FDC Controller: Enable
Onboard Serial Port 1: 3F8/IRQ4
Onboard Serial Port 2: 2F8/IRQ3
UART2 Mode: Standard
Onboard Parallel Port: 378/IRQ7
O
nboard Parallel Mode: SPP
O
nboard Serial Port 3: 3E8/IRQ10
O
nboard Serial Port 4: 2E8/IRQ5
W
DT Active When Power ON: 63 sec
PS/2 Mouse Function: Enable
USB Controller: Enable
USB Keyboard Support: Enable
Ethernet Boot ROM: Disable
Panel Type: 800x600 TFT
Esc :Quit :Select Item
F1 :Help PU/PD/+/- :Modify
F5 :Old Value (Shift)F2 :Color
F6 :Load BIOS Defaults
F7 :Load Setup Defaults
IDE Primary/Secondary Master/Slave PIO: The four IDE PIO (Programmed
Input/Output) fields let you set a PIO mode. (0-4) for each of the four IDE devices that
the onboard IDE interface supports. Modes 0 through 4 provides successively
increased performance. In Auto mode, the system automatically determines the best
for each device.
Primary/Secondary Master/Slave Ultra DMA: Ultra DMA/33 implementation is possible
only if your IDE hard drive supports it and the operating environment includes a DMA
driver (Windows 95, OS/2 or a third-party IDE bus master driver). Select Auto to
enable BIOS support.
