5.2 Setup report
and the description of device parameters see the following paragraphs.
DEVICE NAME and
FIRMWARE MODULES
RELEASE
PRINTING HEAD
STATUS
DEVICE
STATUS
KEYS FUNCTIONS
PRINTER
PARAMETERS
PRINTER SETTINGS
1
----------------------------------------------------------------------------
PRINTHEAD WORKING GOOD!
PRINTER TYPE ....................................<device model>
PRINTING HEAD TYPE ........................<head model>
INTERFACE ..........................................RS232
PROGRAM MEMORY TEST.................OK
DYNAMIC RAM TEST...........................OK
EXTERNAL MEMORY TEST ................OK
CUTTER TEST......................................OK
HEAD VOLTAGE [V] = 23,37
HEAD TEMPERATURE [°C] = 25
CUT COUNTER = 1
Printer Emulation............................. : SERVICE
RS232 Baud Rate ........................... : 115200 bps
RS232 Data Length......................... : 8 bits/chr
RS232 Parity ................................... : None
USB Mass Storage.......................... : Enabled
USB Address Number ..................... : 0
Print Mode ....................................... : Normal
After Cut Ejecter Type ..................... : Presenter
Speed / Quality................................ : High Speed
Paper Threshold .............................. : 40%
Notch/B.Mark Position..................... : Transparent
Notch/B.Mark Threshold.................. : 60%
Service Alignment Type................... : Edge
USB Virtual COM............................. : Disabled
Near Paper End............................... : Disabled
Casing Type..................................... : Plastic
PrintHead Test PowerOn ................. : Disabled
[ LF ] enter Setup
[ FF ] skip Setup
<device name>
SCODE. <code>
DCODE. <code>
FCODE. <code>
60
