5.5 Ethernet parameters
Models with ETHERNET port
The parameters marked with the symbol
D
are the default values.
Settings remain active even after the device has been turned off and they are stored in non-volatile memory.
DHCP CLIENT Setting of the DHCP protocol:
Disabled
D
= protocol disabled
Enabled = protocol enabled
IP ADDRESS IP address of device; this parameter is assigned by the network administrator.
NOTE: Press the FEED key to modify the value of the highlighted digit.
Pressing OPEN key to move the cursor on the next digit (if the cursor is on the latest digit, proceed to next
parameter by pressing the OPEN key).
SUBNET MASK
NOTE: Press the FEED key to modify the value of the highlighted digit.
Pressing OPEN key to move the cursor on the next digit (if the cursor is on the latest digit, proceed to next
parameter by pressing the OPEN key).
DEFAULT GATEWAY
network.
NOTE: Press the FEED key to modify the value of the highlighted digit.
Pressing OPEN key to move the cursor on the next digit (if the cursor is on the latest digit, proceed to next
parameter by pressing the OPEN key).
DOMAIN NAME SYSTEM
-
TCP PRINTER PORT This parameter sets the TCP port number.
-
MAC ADDRESS
univocal.
ATTENTION: Any changes to network parameters will interrupt browser connection. If the server not responding you
must reconnect to the new IP address set.
67
