3.3 Connections
Models without ETHERNET port
POWERRS232
PC
USB device
PC
serial device
Power supply
Power supply cable
(supplied with
TK180)
USB
standard cable
(supplied with
metallic TK180)
Serial
standard cable
(supplied with
metallic TK180)
Correctly insert the
power supply
connector (see
following paragraphs)
ATTENTION: In some conditions, we recommend the installation of a ferrite core on the power supply cable.
NOTES: If serial and USB connectors are inserted, communication port is USB.
For some models, only the internal printer group is represented.
