3.6 Status messages
The Status LED indicates hardware status of device. Given in the table below are the various LED signals and the cor-
responding device status.
STATUS LED DESCRIPTION
-
OFF DEVICE OFF
GREEN
ON DEVICE ON: NO ERROR
GREEN
COMMUNICATION
STATUS
x 1 RECEIVE DATA
x 2 HEADING OVER TEMPERATURE
x 3 PAPER END
x 4 POWER SUPPLY VOLTAGE INCORRECT
x 5
RECEPTION ERROR
(PARITY, FRAME ERROR, OVERRUN ERROR)
x 6 COMMAND NOT RECOGNIZED
x 7 COMMAND RECEPTION TIME OUT
x 10 LOW PAPER
(1)
GREEN
UNRECOVERABLE
ERROR
x 11 CUTTER ERROR
NOTE:
(1) : Only for models with the low paper sensor kit assembled (see chapter 10).
20
