5.4 Switch the device ON
1
2
IN DC 24V 1.8A
TL60
IN DC 24V 2.2A
TL80
COM 24Vdc
COM 24Vdc
EXTERNAL
POWER SUPPLY
(OPTIONAL)
Power supply cable
(supplied)
Connect the power supply cable to the external power supply unit and to the device.
Use the type of electrical power supply indicated on the label.
The green status LED turn on
and the device is ready.
