5.5 Loading the paper roll
To change the paper proceed as follows.
TL60 STD, TL60 EJ
Wait until the paper is
automatically loaded.
Insert the paper into the the input mouth
so that it unrolls correctly, as shown in figure.
Switch ON the device
(see previous paragraphs).
Inser the paper roll on the pin
of the roll holder.
COM 24Vdc
Power supply cable
(supplied)
VROOM
4
1
3
2
36
