Custom Audio Electronics TL60 - Page 37

TL80
Wait until the paper is
automatically loaded.
Insert the paper into the the input mouth
so that it unrolls correctly, as shown in figure.
Switch ON the device
(see previous paragraphs).
Adjust the paper width
(see previous paragraphs).
Inser the paper roll on the pin
of the roll holder.
VROOM
COM 24Vdc
Power supply cable
(supplied)
5
2
1
4
3
37
