8.4
Power supply dimensions cod.963GE020000046 (optional)
Length
127 mm
Height
35.5 mm
Width
56 mm
NOTE:
35.5
1
2
3
n.c.
GND
+24V
56
127
DC OUTPUT WIRE
AC INLET
75
74
76
