4.3 Connections

COM 24Vdc
PC
USB device
PC
serial device
Power supply
Serial cable
Power supply cable
(supplied)
Standard
USB cable
ATTENTION: In some using conditions, we recommend the installation of a ferrite core on the power supply cable.
NOTE: When the RS232 and USB communication cables are connected to the printer at the same time, communication
takes place via the USB port.
