To set a negative value of the “B. Mark Distance” parameter is useful in cases where the alignment point refers to the black
mark printed on the previous ticket or where the desired cutting line is placed in the middle of the alignment black mark. In
the following images, the value of “B. Mark Distance” parameter is set to -A.
PRINTING DIRECTION
point
front
-A
the printing head and the cutter (cutting line), where:
device
A = distance between the
alignment sensor and the printing line
B = distance between the
printing line and the cutting line
TL60 11,7 mm 13 mm
TL80 12,5 mm 12,5 mm
NOTE:
95
