CyberGuard sg565 User Manual

Virtual Private Networking
212
Select the Internet interface the IPSec tunnel is to go out on. In this example, select
default gateway interface option.
Select the type of keying for the tunnel to use. In this example, select the Aggressive
mode with Automatic Keying (IKE) option.
Select the type of IPSec endpoint this CyberGuard SG appliance has. In this example,
select the static IP address option.
Select the type of IPSec endpoint the remote party has. In this example, select the
dynamic IP address option.
Select the type of authentication for the tunnel to use. In this example, select the
Preshared Secret option.
Click the Next button to configure the Local Endpoint Settings.
Local endpoint settings page
Leave the Optional Endpoint ID field blank in this example. It is optional because this
CyberGuard SG appliance has a static IP address. If the remote party is a CyberGuard
SG appliance and an Endpoint ID is used, it must have the form abcd@efgh. If the
remote party is not a CyberGuard SG appliance refer the interoperability documents on
the CyberGuard SG Knowledge Base to determine what form it must take
(http://www.cyberguard.com/snapgear/knowledgebase.html).
Leave the Enable IP Payload Compression checkbox unchecked.
Leave the Enable Phase 1 & 2 rekeying to be initiated from my end checkbox
checked.
Click the Next button to configure the Remote Endpoint Settings.
Remote endpoint settings page
Enter the Required Endpoint ID of the remote party. In this example, enter the Local
Endpoint ID at the Branch Office which was: branch@office
Click the Next button to configure the Phase 1 Settings.
