GETTING TO KNOW YOUR IPC-R1ix
2
GETTING TO KNOW YOUR IPC-R1ix
2.1 Packing List
Item Description Qty
1 IPC-R1ix Fanless Robust Computing System
contain HDD and DDR3 SO-DIMM. Please verify these items
if necessary.)
1
2 Accessory box, which contains
● Cybernet Drivers & Utilities DVD
● Wall-mounting bracket
● M4 screws for wall-mounting bracket
● 3-pin pluggable terminal block
1
2
4
2
2.2 Front Panel I/O Functions
All Input / Output connectors are located on front panel of IPC-R1ix series.
Most connectors like audio, USB, DVI-D, VGA are all designed on front panel.
Isolated DIO 2
Reset
COM 1
COM 2
| LAN 2
VGA
DVI-D
V+
1
2
| LAN 1
V
-
COM 4 COM 3
Isolated DIO 1
On
|
Off
IPC-R1ix
