Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
2
2
1.3 Supported CPU List 4
1.4 Mechanical Dimension 5
CHAPTER 2 GETTING TO KNOW YOUR IPC-R1ix 06
2.1 Packing List 06
2.2 Front Panel I/O Functions 06
2.2.1 Power Button 07
2.2.2 Rest Tact Switch 08
2.2.3 Power, HDD LED Indicator 08
2.2.4 Dual Isolated 8 DI/ 8 DO 09
2.2.5 Serial Port, COM 1, COM 3, COM 4 12
2.2.6 USB 2.0 Port 13
2.2.7 Serial Port, COM 2 14
2.2.8 USB 3.0 Port 15
2.2.9 10/100/1000 Mbps Ethernet Port 15
2.2.10 DisplayPort 17
2.2.11 DVI-D Connector/ HDMI Connector 17
2.2.12 VGA Connector 18
2.2.13 Audio Connector 19
2.2.14 DC-in Power Terminal Block 19
20
2.3 Main Board Expansion Connectors 21
2.3.1 J2 Miscellaneous Pin Header 23
2.3.2 CFast Card 24
2.3.3 CN9, CN11, J3 LVDS 26
2.3.4 CN16, CN17 SATA-III Connector 29
