Cybernet IPC-R1ix - Fan

41
GETTING TO KNOW YOUR IPC-R1ix
Pin No. Pin No.
1 GND 3 Fan-speed sense
2 +12V (1.5A max)
AN power connector supported for better thermal required.
2.3.12 Fan 1
