GETTING TO KNOW YOUR IPC-R1ix
The IPC-R1ix system comes with a CFast socket on the front panel for
Type-I / Type-II Compact Flash card. It is implemented by a SATA II Port from
QM77 PCH.
Be sure to disconnect the power source and unscrew the CFast socket cover
before installing a CFast card. The IPC-R1ix does not support the
CFast hot swap and PnP (Plug and Play) functions.
It is necessary to remove power source first before inserting or removing the
CFast card. The following table shows the pinouts for CFast port:
CN2 CFast
Pin No. Pin No.
S1 GND PC6 NC
S2 SATA_TX_P2 PC7 GND
S3 SATA_TX_N2 PC8 NC
S4 GND PC9 CFAST_LED_N
S5 SATA_RX_N2 PC10 NC
S6 SATA_RX_P2 PC11 NC
S7 GND PC12 NC
PC1 NC PC13 +3.3V
PC2 GND PC14 +3.3V
PC3 NC PC15 GND
PC4 NC PC16 GND
PC5 NC PC17 NC
