GETTING TO KNOW YOUR IPC-R1ix
Pin No.
CN11 Channel A CN9 Channel
1
LDDC_CLK LDDC_CLK
2
LDDC_DATA LDDC_DATA
3
PANEL_VDD (+3.3V or +5V by
jumper)
PANEL_VDD(+3.3V or +5V by
jumper)
4
LA_ DATA0_P LB_ DATA0_P
5
LA_ DATA3_P LB_ DATA3_P
6
LA_ DATA0_N LB_ DATA0_N
7
LA_ DATA3_N LB_ DATA3_N
8
PANEL_VDD (+3.3V or +5V by
jumper)
PANEL_VDD (+3.3V or +5V by
jumper)
9
GND GND
10
LA_ DATA1_P LB_ DATA1_P
11
LA_ CLKP LB_ CLKP
12
LA_ DATA1_N LB_ DATA1_N
13
LA_ CLKN LB_ CLKN
14
GND GND
15
GND GND
16
PANEL_BACKLIGHT (+12V) PANEL_BACKLIGHT (+12V)
17
LA_ DATA2_P LB_ DATA2_P
18
PANEL_BACKLIGHT (+12V) PANEL_BACKLIGHT (+12V)
19
LA_ DATA2_N LB_ DATA2_N
20
GND GND
