3
GENERAL INTRODUCTION
Ethernet
LAN 1 Intel
®
82579LM Gigabit LAN, Wake on LAN, PXE Support,
iAMT 8.0
LAN 2 Intel
®
82574L Gigabit LAN, Wake on LAN, PXE Support
Power
Power Input
3-pin terminal block for DC-in: V+, V-, Frame Ground
ATX: 2-pin Remote Power On/Off Switch
Power Input Voltage DC-in 6V to 36V
Power Adapter AC to DC +24V/ 5A, 120W Max. (Optional)
Protection OnBoard LT4356 for Power Input High Voltage Surge
Protection
Others
Trusted Platform
Module (TPM)
Watchdog Timer Reset: 1 to 255 sec/ min Per Step
HW Monitor Temperature, voltages auto throttling control when CPU
overheats
Mechanical
Chasis Construction Aluminum Housing
Size (W x D x H) 137mm x 252mm x 210mm (5.4” x 9.9” x 8.3”)
Weight 3 kg (6.6 lb)
Mounting Wall-mount by Mounting Bracket
Environmental
Operating Temperature -25°C to 70°C (-13°F to 157°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 10% to 95% Humidity, Non-condensing
Relative Humidity 95% at 70°C
Vibration Random: 5Grms @5 to 500 Hz according to IEC68-2-64
Sinusoidal: 5Grms @5 to 500 Hz according to IEC68-2-64
Shock Operating, 50 Grms, Half-sine 11 ms Duration (w/ SSD,
According to IEC60068-2-27)
EMC CE, FCC
