EN
41
CLICK!
CLICK!
6
7
Squeeze the Lock-o Handle Release and lift
up the lock o.
Once open, Lock-o will remain open on its
own.
Attach both LATCH Connectors to the Lower
LATCH Anchors. Each should make an audible
CLICK when attached. Make sure they are
attached by pulling firmly on the connectors.
Push Base against vehicle seat back. Tension
the LATCH strap by pulling on the LATCH
Adjuster Strap to take the slack out of the
LATCH Strap, just enough to make it snug.
At this point, the LATCH strap should only be
snug as the Lock-o will tighten the system
fully.
NOTE : To store excess strap, after tightening
LATCH, place the free end of the strap flat
under the base.
NOTE: Only items approved by Cybex are
allowed under the base.
.
5
6
7
5
