CYBEX 525T Service Manual

Remove front roller
1.
Moving parts hazard. To avoid serious injury slowly release tension to
parts.
Loosen the left mounting bolt using a 9/16” Socket wrench.
Qty.DescriptionItem
1Front roller1
1Drive belt2
1Tensioning slot3
1Mounting bolt4
2. Loosen the right mounting bolt using a 9/16” Socket wrench.
3. Remove the front roller and slide the drive belt off of the front roller.
Install front roller
1. Slide the front roller into the running belt.
2. Slide the drive belt around the front roller before attaching the front roller.
Qty.DescriptionItem
1Front roller1
1Drive belt2
1Tensioning slot3
1Mounting bolt4
Page 115 of 199
