Remove top steps
1. Remove the five screw covers from the right top step using a flat head screwdriver.
Qty.DescriptionItem
5Screw cover1
5Screw2
5Screw cover base3
1Top step, right4
2. Remove the five screws and five screw cover bases securing the right top step using a Phillips
screwdriver.
3. Repeat steps for the left top step.
Remove rear roller
1. Remove the two rear roller bolts, washers, bushings and rear roller nuts (one roller bolt on each
side) using a 3/4” Socket wrench.
Loosen each bolt evenly, making sure not to loosen either bolt too many turns before moving to the
other bolt.
Qty.DescriptionItem
1Rear roller nut1
1Bushing2
1Washer3
1Bolt4
1Rear roller5
2. Lift one side of the rear roller and slide the roller out of the running belt.
Page 129 of 199
Cybex 525T Treadmill Part Number
