CYBEX 530R User Manual

Cybex 530C and 530R Owner’s Manual
D. Check off ( ) each item in the hardware pack as you find it. See Figure 2.
Setup
and Assembly
Page 5-4
Item Qty Part Number Description
9 4 HS-18183 Screw, 5-16-18 X .75, SHCS (Socket Head Cap Screw)
10 8 HW-53018 Washer, 5-16” Split
11 2 HS-15706 Screw, 8-16 x .50, PNHD
12 4 HS-18157 Screw, 5-16-18 X 1.25, BTN, BLK
13 1 HS-41006 Screw, 10-24 x .50, SLFTP, BLK
14 1 HX-00438 3/16” Allen wrench
15 1 HX-17117 1/4” Allen wrench
Figure 2
Hardware
#9#5
#2
#10
#12
#9
#10
#4
#13
#11
#3
#1
#10 #11
#12
#13 #14 #15
