Cybex 530C and 530R Owner’s Manual
Setup
and Assembly
Page 5-8
1. Unpack and verify contents of the unit.
A. Check to be sure that the following items are present. Check off ( ) each item as you find it.
See Figure 1. If any of the parts are missing contact Cybex Customer Service.
Figure 1
Cybex 530R Cycle Assembly
Item Qty Part Number Description
1 1 Varies Base with covers attached
2 1 Varies Console Assembly
3 1 PL-18235 Front Cap (in box)
4 1 AX-18361 Hardware pack (in box)
5 1 LT-18171-4 Owner’s Manual (in box)
6 1 LT-18260 Assembly poster
7 1 LT-18259 Warranty sheet
8 1 NA Seat Back Assembly
NOTE: NA means not applicable.
#5 #6 #7
#4
#8
#3
#1
#2
To Next Page
