Front routing: Skip to Install uprights on page 21.
Back routing:
1. Remove the four screws securing the front cover to the base using a Philips screwdriver.
Qty.Description
1Front cover1
4Screws2
2. Remove front cover.
3. Remove the two screws securing the right end cap using a Philips screwdriver.
Qty.Description
2Screws1
1Right end cap2
4. Remove the right top step by inserting a long 3/8" drive socket extension into the right top step and
prying backwards.
Qty.Description
13/8" Drive Socket Extension1
1Right Top Step2
Page 19 of 88
Cybex 625T Treadmill Part Number LT-23221-4 H
