CYBEX 750T Service Manual

Cybex 750T Treadmill Service Manual
Service
Page 4-4
Display test
Press and hold the Programs key to light up the Bar Graph Matrix LED’s. Press and hold the Manual
key to light up the 5 x 7 Dot Matrix LED’s and Data Readout LED’s. Press and hold the Fit Test key to
light up the 7-Segment Displays.
Motion sensor test
The motion sensor is located to the left of the estop key. While standing to the side of the treadmill, wave
your hand in front of the motion sensor. An audible beep will indicate the sensor is working. See
Figure 3.
Figure 3
Motion
Sensor
E-Stop Key
E-Stop key/Stop test
Pull out the e-stop key to display “Emergency Stop”. Insert the e-stop key back into the console. See •
Figure 3.
Press the • Pause/end key once to display “Emergency Stop”. Press the Pause/end key a second time
to return to “Static IO test”.
Pressing the • STOP button will test the stop key and exit the Static IO test.

CYBEX 750T Specifications

General

Motor	3.0 HP
Incline Range	0% - 15%
Max User Weight	400 lbs
Heart Rate Monitoring	Wireless Receiver
Weight	350 lbs
