CYBEX 770T Service Manual

•
Display watchdog resets cause a pair of codes, 9 and 99, to appear in sequence
NOTE: Errors < 90 are console generated. The console software has determined an error condition
exists that either doesn’t involve the drive or hasn’t caused the drive to malfunction. All errors
generated by or reported by the motor controller are 90 or greater.
Access error log
Press and hold Cybex logo for 6 seconds to access
Screen Lock and Toolbox.
CYBEX LOGO
Press and hold language logo for 6 seconds to ac-
cess Screen Lock and Toolbox.
LANGUAGE ICON
1. Tap the Access Toolbox icon to display the Access to Toolbox login screen.
2.
Enter the sequence: .
3. At the main Toolbox screen, tap the OEM Diags icon, then the Error Log icon.
Error code list
DescriptionError Code
Drive did not start (No Speed at Startup)
Error 1
GFX Communications issue
Error 2
Speed Irregularity / Underspeed
Error 3
Upper Display Communications issue
Error 4
Drive Communication Issue
Error 5
Membrane Fault (stuck key)
Error 6
Controller Over-Current (Fold-back)
Error 7
Approaching Over-Temperature
Error 8
MCC Watchdog Triggered
Error 9
Motion Sensor Blocked
Error 10
Motion Sensor Defective
Error 11
Graphics Board Watchdog Triggered
Error 12
Upper Display watchdog Triggered
Error 13
Drive Error Unknown
Error 14
Embedded A/V Device Failure
Error 15
Membrane Fault (No Membrane)
Error 16
Membrane Fault - Stuck Thumb Control
Error 18
Page 75 of 261
Cybex 770T/790T Treadmill Part Number

CYBEX 770T Specifications

General

Weight Capacity	400 lbs
Speed Range	0.5 - 12.4 mph
Incline Range	0 - 15%
Running Surface	22" x 60"
Heart Rate Monitoring	Yes
Display	15" Touch Screen
