Cybex 750A/750AT Arc Trainer Owner’s Manual
Safety
Page 1-6
NOTE: This is the minimum recommended service.
NOTE:
If using optional AC Power Kit, unplug
unit from wall outlet.
Determine
mileage.
1.
Start
pedaling unit.
2.
During initial countdown, press CLEAR 9,9,9 ENTER.
The firstmenu item is ODOMETER. Press ENTER
to view accumulated distance.
First 500 Miles / 800 Km
A
Check drive belts for tension and wear.
Every 5000 Miles / 8000 Km
A
Check drive belts for tension and wear.
B
Move unit and vacuum underneath.
C
Remove access cover to clean
inside - u
Every 20,000 Miles / 32000 Km
D
Check elevation assembly and replace
worn p
Service Schedule
U6
Q1
L3
T1
C25
J2
J1
J5
J4
D2
D36
C23
C24
K1
K2
K3
J8
J6
L5
10
9
3
4
2
1
7
8
6
5
LED 1 - Console Transmit
LED 2 - Console Receive
LED 3 - Battery Charge Status
LED 4 - Battery Charge Status
LED 5 - Powered from Generator
LED 6 - Brake Current
LED 7 - +12V External Power
LED 8 - Display Voltage (+12V)
LED 9 - Elevation Motor Down
LED 10 - Elevation Motor Up
Diagnostic LED Designation
All maintenance activities shall be performed by qualified
personnel. Failure to do so could result in serious injury.
NOTE:
Refer to Service Manual for detailed trouble shooting information.
Set up (CLEAR 7,5,0, ENTER)
Diagnostic (CLEAR 8,8,8, ENTER)
Statistics (CLEAR 9,9,9, ENTER)
Entering Hidden Menus
A.Clean Brake/Enclosure
B.Check Connections
C.Check Fuse
D.Check Battery
750A-329-4
8Approaching Over-Temperature
9Display watchdog triggered
B,H,K
22Speed irregularity - Low speed and
High power
23Speed irregularity - High speed and
Low power
24Incline moving too slowly
D,F,J
25Incline movement feedback
stopped
26Incline disabled
C,D,E,F,J
27Low Battery
B,G,I,K
28Over-Temperature
A,B,C,G
29Controller watchdog trigge
red - EEPROM or Memory Error
Error Codes
BATTERY STATUS FROM LEDs 4 AND 3
NO
BATTERY
PRE
CHARGE
HIGH
CHARGE
TRICKLE
CHARGE
4
3
4
3
4
3
4
3
Warning decal part number - 750A-329-4
All maintenance activities shall be performed by qualified
personnel. Failure to do so could result in serious injury.
WARNING
WARNING
DE-17155-4 A
Hot flywheel! Wait until it
cools before servicing.
Warning decal part number
DE-17155-4
NOTE: Decal on inside of cover.
