CYBEX Arc Trainer 750A User Manual

Cybex Arc Trainer 750A/750AT Owner’s Manual
Maintenance
Page 4-2
1. Read and understand warnings listed in this chapter and in Chapter 1 – Safety. Read and understand all
instructions in this section.
2. During maintenance, disconnect the external power source. If unit has the optional AC Power Kit, unplug the
power cord from the power outlet.
For some maintenance activities it will be necessary to remove and replace the access cover.
Tool Required
Phillips screwdriver•
Preventive Maintenance Activities
Perform regular preventive maintenance to ensure normal operation of unit. Keep a log of all maintenance actions
to assist in staying current with all preventive maintenance activities.
NOTE: Cybex is not responsible for performing regular inspection and maintenance actions of this unit. Instruct
all personnel in equipment, inspection and maintenance. Require all personnel to report and record all
accidents.
Remove Access Cover
1. Using a Phillips screwdriver, remove the two
lower screws securing the access cover.
See Figure 1.
2. Using a Phillips screwdriver, remove two
upper screws securing the access cover. See
Figure. 1
3. Remove the access cover.
Warning: The fl ywheel may be hot. Wait until
it cools before servicing.
Attach Access Cover
NOTE: Do not over tighten screws.
1. Using a Phillips screwdriver, replace and
tighten the two upper screws removed in
step 2 Remove Access Cover.
2. Using a Phillips screwdriver, replace and
tighten the two lower screws removed in
step 1 Remove Access Cover.
3. Test unit for proper operation.
Figure 1
Lower Screws (2)
Access
Cover
Upper Screws (2)
