Cybex 750A/750AT Arc Trainer Owner’s Manual
A1 6 600A-311 SPACER, FLANGE
A2 1 600A-362 LABEL, BIOSIG PATENT
A3 2 610A-351 PIVOT PIN
A4 2 610A-358 INSERT, PLASTIC 1.188 OD X .281
ID
A5 2 610A-395 ASSY, ARM CRANK
A6 1 740A-350 COVER, LEFT HAND
A7 1 740A-351 COVER, RIGHT HAND
A8 1 740A-352 COVER, FRONT ACCESS
A9 2 740A-353 COVER, CRANK
A10 1 740A-354 COVER, ELEVATION MOTOR
A11 1 740A-370 TRAY, MAIN
A12 1 740A-371 TRAY, INSERT
A13 1 740A-372 COVER, PIVOT, TOP LH
A14 1 740A-373 COVER, PIVOT, TOP RH
A15 1 740A-374 COVER, PIVOT, BOTTOM LH
A16 1 740A-375 COVER, PIVOT, BOTTOM RH
A17 1 750A-101 DRIVE FRAME ASSEMBLY
A18 1 750A-115 LINKAGE ASSY, LH
A19 1 750A-116 LINKAGE ASSY, RH
A20 2 750A-201 W/ LEG
A21 1 750A-204 W FOOT PLATE ARM, LR
A22 1 750A-205 W FOOT PLATE ARM, RR
A23 2 750A-312 TUBE, SPACER
A24 2 750A-325 TUBE, SPACER
A25 1 750A-329-X* DECAL, WARNING & ERROR
CODE
A26 1 750A-349 DECAL LOGO, ARC
A27 1 750A-365 COVER, CONTROLLER
A28 1 750A-390 TAB, PC MOUNT
A29 1 750A-396 FERRITE CLAMP-ON .40 ID
A30 1 750AT-112 FOOT PLATE ARM ASSY, LH
A31 1 750AT-113 FOOT PLATE ARM ASSY, RH
A32 2 750AT-114 HANDLE LINKAGE ASSY
A33 1 750AT-117 HANDLE ASSY, LH - 750AT
A34 1 750AT-118 HANDLE ASSY, RH - 750AT
A35 1 750AT-200 W/ MAIN FRAME - 750AT
A36 1 750AT-213 CONSOLE MOUNT, 750AT
A37 2 AF-16694 ASSY, BEARING, 1.00 INCH
PILLOW BLOCK
A38 2 AP030055 PIN, HEADLESS GROOVED Ø.500
X 2.00
A39 1 AW-20935 CABLE, 750A, CONSOLE
HARDNESS
A40 1 AW-21748 CABLE, 750A CHR FRAME
A41 1 AW-21750 CABLE, 750A SALUTRON GND
A42 4 BR030228 RETAINING RING, .500 EXTERNAL
A43 2 750A-418 RUBBER SLEEVE
A44 2 CW-17231 WHEEL, TENSIONER
A45 2 DE-17339 DECAL, CYBEX VORTEX
A46 1 DE-21625 LABEL, ETL CSA CE, 750A
A47 1 EC-21743 SENSOR SALUTRON COMBO
BOARD
A48 4 FB030256 BEARING, BALL, 1.181 Ø, DOUBLE
ROW
A49 4 FC030003 TOLERANCE RING
A50 4 FC030011 TOLERANCE RING
A51 8 HB-17036 BEARING, BALL, .750 DIAMETER
A52 4 HB-17280 BEARING ROLLER 3”
A53 4 HC700415 BHSCS .375-16 X .75
A54 4 HC700428 BHSCS .375-16 X 2.25
A55 10 HC701226 BOLT, HHCS .375-16 x 2.0
A56 4 HC701234 SCREW, HHCS .375-16 x 3.00
A57 2 HF540200 GROMMET, NYLON
A58 2 HG700022 LEVELING GLIDE, .375-16
A59 4 HM582514 SCREW, PAN HEAD PHILPIPS 10-32 x
.62 BLK
A60 2 HN624901 LOCKNUT, .250-20 NYLON BLK ZN
A61 2 HN704000 HEX NUT .375-16
A62 8 HN704901 LOCKNUT, .375-16 NYLON
A63 8 HN704902 LOCKNUT, .375-16 NYLON
A64 6 HS307601 WASHER, FLAT .281 ID X .500 OD X
.062
A65 4 HS307602 WASHER FLAT .281 ID X 1.000 OD. X
.063
A66 2 HS307603 WASHER, FLAT .281 ID X .734 OD X
.063
A67 2 HS328300 LOCKWASHER SPLIT .312
A68 4 HS347600 WASHER, SAE .375
A69 4 HS347602 WASHER, FLAT .390 ID x 1.500 OD x
.124
A70 10 HS347700 WASHER, USS .375
A71 4 750A-446 WASHER, .765 ID x 1.000 OD x .125
A72 2 HT102214 PHIL, HEX, WASHER HD, TYPE 23,
10-24
A73 8 HT512522 TAP SC 10-24 X 1.50 TYPE WB PN
A74 8 HT552511 SCREW, TAP 8-16 x .38 PLASTITE
BLACK
A75 10 HT552512 PAN HD PHIL HD SELF TAPPING, 8-16
x .50 TYPE WB
A76 9 HT552515 TAP SC NO. 8-16 X .75 PLASTITE PN
HD PHIL BLK
A77 13 HT572512 TAP SC NO. 10-24 X .50 PN HD PHIL
A78 4 HT592526 TAP SC 10-12 X 2.00 TYPE A PN HD
PHIL
A79 2 HX-17023 PIN, SPRING .1875 x .75 LG, TYPE 420
A80 12 HX622815 SHCS .250-20 UNC-3A SS
A81 4 HX700415 BHSCS .375-16 X .75 SS
A82 2 JD623324 BOLT, SHOULDER .312 x 1.75 .250-20
A83 1 MR-18446 MOTOR, ELEVATION, 115 V
A84 6 PL-16535 CAP, LINKAGE ROD, 2.00 OD
A85 1 750A-200 W/MAIN FRAME - 750A
A86 1 DE-17155-X* DECAL, WARNING
A87 1 750A-121 CONSOLE
A88 1 750A-330-X* DECAL,WARNING
A89 2 740A-378 FOOT PLATE
A90 2 740A-381 TOE CAP
A91 4 HX700412 BHSCS .375-16 X .50SS
A92 1 750A-403 WASHER, SADDLE, .390 ID X .750 OD
X .06
A93 1 HX700428 BHSCS .375-16 X 2.25 SS
A94 1 750A-124 HANDLE ASSY - 750A
A95 1 750A-213 CONSOLE MOUNT, 750A
A96 1 750A-372-X* DECAL, WARNING
A97 1 DE-17219-X* DECAL, WARNING
A98 1 CP-21072 MONITOR CYBEX 13.3” LCD, ATSC-
NTSC DIGITAL PEM
A99 1 CP-21073 MONITOR CYBEX 13.3” LCD, PAL-
DVB-SECAM DIGITAL PEM
A100 1 TR-21265 AC POWER ADAPTOR (POWER CORD
VARIES)
A101 1 750A-404 CABLE 750A CHR GRIP
NS 1 TR-18448 POWER, PEM
NS 1 5750-X* OWNERS MANUAL
NS 1 750A-402 750A ASSEMBLY POSTER
NS 1 750A-391 COMMERCIAL ARC WARRANTY
SHEET
NS 1 750A-392 CONSUMER ARC WARRANTY SHEET
NS 1 750A-393 750AT ASSEMBLY POSTER
ITEM QTY PART NO. DESCRIPTION
ITEM QTY PART NO. DESCRIPTION
Appendix C – 750A/750AT Parts List
NS=Not Shown
*Language Key
1-German 2-French 3-Spanish 4-English 6-Japanese 7-Swedish 8-Russian
Parts List
Page C–1
