CYBEX Arc Trainer 750A User Manual

Cybex 750A/750AT Arc Trainer Owner’s Manual
Exploded Views
Page D–14
Console Assembly – Part Number 750A-121
ITEM NO. QTY. PART NUMBER DESCRIPTION C1 1 740A-384 CONSOLE, FRONT C2 1 740A-385 CONSOLE, BACK C3 1 740A-386 CONSOLE, TOP C4 1 740A-389 DUCT, FAN RIGHT C5 1 740A-390 DUCT, FAN LEFT C6 1 740A-391 COVER, LOWER CONSOLE, NON-AV C7 1 750A-102 PCA, SPLIT DISPLAY UPPER C8 1 750A-105 FAN,12VDC,120X120MM,CFM30 C9 1 750A-357 CONSOLE INNER PLATE C10 1 750A-387 DIFFUSER, .60 OD DISC C11 1 DE-21240-X* ENUNCIATOR C12 1 AD-21194 PCA, 750A DISPLAY C13 1 AW-20934 CABLE, 750A CONSOLE C14 1 SW-20928-X* OVERLAY C15 1 AW-21747 CABLE, 750A C16 2 HF540200 GROMMET, NYLON C17 3 HJ542520 SCREW, SEMS, 8-32 X 1.25 PNHD PHIL EXT ZN C18 2 HJ692560 SCREW, SEMS, M4 X 0.7 X 10mm PNHD PHIL EXT ZN C19 4 HS307400 LOCKWASHER INT TOOTH .250 SS C20 14 HT552509 SCREW, TAP 8-16 x .31 PLASTITE C21 13 HT552512 PAN HD PHIL HD SELF TAPPING, 8-16 x .50 TYPE WB C22 2 HT552517 TAP SC NO. 8-16 X 1.00 TYPE WB PNHD PHIL BLK C23 4 JC620412 BHSCS .250-20 X .50 C24 1 DE-21691 DECAL 750A C24 1 DE-21692 DECAL 750AT C25 1 DE-20929-X* UPPER KEYBOARD NS 1 750A-396 FERRITE CLAMP-ON .40 ID
NS = Not Shown
