1. Remove LATCH anchors from storage. See page 29.
2. Unfold the Load Leg from underneath the Base.
3. Position Base on a rear vehicle seat. If a hump is present on
the floor of the vehicle, see page 30 for important information
on using the Load Leg in this seating position.
4. Adjust the Leveling Foot to achieve the correct range for your
child's weight as shown on the Level Indicator. See page 31.
5. Fully open Belt Tensioning Plate by turning the ORANGE Locking
Lever to the
OPEN position and lifting up on the Plate.
Once open, the Belt Tensioning Plate will remain open on its own. The
Locking Lever should be in the OPEN position with the Plate open.
6. Attach both LATCH Connectors to the Lower LATCH Anchors.
Each should make an audible
when attached. Make sure
they are attached by pulling firmly on the connectors.
7. Push Base against vehicle seat back. Tension the LATCH strap by pulling
on the LATCH Strap Tensioning Loop to take the slack out of the LATCH
Strap, just enough to make it taut. Tuck the loose end of the strap
under the base so it WILL NOT INTERFERE with the closing of the Belt
Tensioning Plate or the connection of the Infant Carrier to the Base.
At this point, the LATCH strap should be taut. The Belt Tensioning Plate
will tighten the system fully.
32
(4–22 kg)
1,8–10 kg
(4–22 kg)
(22–35 lb)
10–15,9 kg
(22–35 lb)
Front of vehicle
2
3
4
5
1
6
7
Installing the Base using LATCH
