Securing the Child
1. Loosen Harness by firmly pressing down the Harness Adjustment
Button
a
while pulling forward on both straps at shoulder level.
b
2. Press RED button on Harness Buckle to release Tongues.
3. Separate Chest Clip and spread straps apart. Place child in
Infant Carrier in seated position making sure their bottom
is in the seat, and their back is fully supported.
4. Pull Harness straps over each arm onto shoulders and around the hips.
Make sure Buckle Pad and Harness Buckle are between the legs.
Newborns tend to draw arms and legs close to their bodies. Gently extend
each limb to allow for proper Harness positioning. Be mindful of especially
sensitive areas.
5. Buckle by inserting one Tongue at a time into the
Harness Buckle listening for an audible with each
one. Make sure Harness Straps are not twisted.
6. Connect the Chest Clip listening for an audible .
WARNING!
DEATH or SERIOUS
INJURY can occur
• MAKE SURE Harness straps are AT or BELOW child's shoulders. If not, refer
to Adjusting Harness Height on page 18, or the Infant Insert section found
on page 19.
• ALWAYS check Harness Buckle to make sure it is securely latched..
20
2
3
4
5
1
6
a
b
Using the Infant Carrier

CYBEX ATON 2 Specifications

General

Height Capacity	Up to 32 inches
Base Included	Yes
Side Impact Protection	Yes
Recline Positions	Multiple
Harness Type	5-point harness
Removable Cover	Yes, machine washable
Weight Capacity	4-35 lbs
Installation Type	LATCH, Seat Belt
Safety Standards	FMVSS 213
Installation	LATCH system or seat belt
Base Compatibility	Compatible with CYBEX Aton Base 2
Stroller Compatibility	Compatible with CYBEX strollers
Additional Features	Linear Side-impact Protection (L.S.P. System)
