1. Position Infant Carrier on a rear vehicle seat, with the foot
end firmly against the back of the vehicle seat.
2. Route vehicle lap belt under both Belt Guides. BUCKLE THE BELT.
3. Push Infant Carrier firmly into vehicle seat, pressing down near the crotch
strap between the child’s legs, while removing slack from the lap belt.
4. If necessary, tuck the loose end of the lap belt out of the way.
5. Check the recline angle. Adjust the seat angle until the RED Level
Line on the Infant Carrier is level with the ground. A tightly rolled
towel or pool noodle may be placed under the Infant Carrier
near the vehicle seat back to adjust the angle. See page 43.
The Aton 2 is allowed to touch the vehicle seat(s) in front of it, as long
the recline angle of the Aton 2 is not affected.
6. Grab the Infant Carrier at the Belt Guides and pull from side to side
and front to back to make sure it is installed correctly. The Infant
Carrier should not move more than 2.5 cm (1 inch) in any direction.
7. If the Infant Carrier is next to a vehicle door or panel,
raise the adjacent LSP device. See page 39.
If the Infant Carrier moves too much, tighten the vehicle belts more and
recheck. You may try a different vehicle seat or installation method, or
both.
WARNING!: To avoid DEATH or SERIOUS INJURY, ALWAYS have the
handle LOCKED in the upright DRIVE/CARRY position while using this
child restraint in a vehicle.
42
Line MUST be level
with ground when
installed without
Base
Line MUST be level
with ground when
installed without
Base
Front of vehicle
2
3
4
5
1
Installing the Infant Carrier without the Base using a Lap Belt Only
