7. Check the recline angle. Adjust the seat angle until the RED
line on the Infant Carrier is level with the ground. A tightly rolled
towel or pool noodle may be placed under the Infant Carrier
near the vehicle seat back to adjust the angle. See page 43.
The Aton 2 is allowed to touch the vehicle seat(s) in front of it, as long
the recline angle of the Aton 2 is not affected.
8. Grab the Infant Carrier at the Belt Guides and pull from side to side
and front to back to make sure it is installed correctly. The Infant
Carrier should not move more than 2.5 cm (1 inch) in any direction.
If the Infant Carrier moves too much, tighten the vehicle belts more and
recheck. You may try a different vehicle seat or installation method, or
both.
9. If the Infant Carrier is next to a vehicle door or panel,
raise the adjacent LSP device. See page 39.
41
Line MUST be level
with ground when
installed without
Base
Line MUST be level
with ground when
installed without
Base
WARNING!
DEATH or SERIOUS
INJURY can occur
• ALWAYS have the handle LOCKED in the upright DRIVE/CARRY position
while using this child restraint in a vehicle.
• NEVER INSTALL the Infant Carrier with BOTH
the Lap and Shoulder Belts routed underneath
Belt Guides.
7
Installing the Infant Carrier without the Base using a Lap and Shoulder Belt
English
