8. Press the Belt Tensioning Plate down with both hands, where
indicated, until it locks into place. The ORANGE Locking Lever will
rotate to the
CLOSE position when the Plate is locked.
If the Belt Tensioning Plate does not lock, try loosening the vehicle belt
slightly.
9. Grab the Base at the Belt Guides and pull from side to side
and front to back to make sure it is installed correctly. The Base
should not move more than 2,5 cm (1 inch) in any direction.
If the Base moves too much, open the Belt Tensioning Plate and remove
a little more slack from the vehicle belt, close Plate and recheck. After
this, if the Base still moves too much, you may need to try a different
vehicle seat location or installation method, or both.
10. Squeeze the Adjustment Handle on the Load Leg and extend it until
the Foot makes firm contact with vehicle floor. Lock Leg into place
using the first hole that will firmly lock it against the vehicle floor.
It may be necessary to lift up slightly on the Base to allow the Foot to
lock into the hole. See page 30.
11. Check that the Recline Angle remained in the appropriate
range for the child's weight. If not, remove Base, adjust
recline angle and reinstall. See page 31.
Make sure that vehicle belt buckle and hardware DO NOT INTERFERE
with correct installation of the Base, or with the connection of the Infant
Carrier to the Base.
37
PRESS
PRESS
(4–22 kg)
1,8–10 kg
(4–22 kg)
(22–35 lb)
10–15,9 kg
(22–35 lb)
Use the FIRST hole that
will lock the Load Leg Foot
firmly against vehicle floor
10
8
9
11
Installing the Base Using a Lap Belt Only
