44
NOTE! Moving the base sideways will further brace the base
with the backrest.
• Always fold out the load leg (4a) until it locks.
• Release the lock of the ISOFIX connectors (5a). Both locks
can be adjusted independently. Push both buttons (6a) and
(7a) simultaneously and pull the ISOFIX connectors out of
the base
to the endstopper.
• The ISOFIX connectors (5a) have to lock into the ISOFIX
anchorage points (2) with an audible click.
• Make sure that the base stays firmly in place by trying to
pull it out of the ISOFIX connect guides.
• The green safety indicator (8a) must be clearly visible on
both ISOFIX release buttons.
• Next, push the base in the direction to the backrest until it is
fully aligned with the backrest.
21
4a
2
8a
5a
6a
7a
