Cybex Pro+ Treadmill Service Manual
Service
Page 4-25
Put the ground wire terminal on the stud on the lower board bracket.B.
Using a 3/8” nutdriver, secure the one nut and one washer over the ground wire terminal.C.
8. Secure the line fi lter.
Using a Phillips screwdriver, secure the two screws that hold the line fi lter to the lower control A.
board bracket.
9. Secure the wires.
Check to see that all of the cables are connected fi rmly in their proper place.A.
Tie the wires back with the wire ties on the base and be sure no wires get pinched.B.
Place the lower board shield in position and push the clips down. C. NOTE: The clips will snap in.
10. Perform IR Compensation procedure.
Follow the A. IR Compensation procedure located in this chapter.
11. Calibrate speed.
Follow the A. Speed Calibration procedure located in this chapter.
12. Secure the motor cover.
Lower the motor cover center into position. See Figure 2.A.
Using a Phillips screwdriver, tighten the three screws on each side. Be sure the screws are B.
catching the center motor cover’s holes. See Figure 2.
Power Cord
NOTE: This procedure will cover the power cable, line fi lter and power switch.
Tools Required
Phillips screwdriver•
3/8” Nutdriver or socket wrench•
ESD (Electro Static Discharge) grounding strap•
! WARNING: Disconnect the power cord before beginning this procedure. Keep wet items away
from inside parts of the treadmill. Electrical shock could occur even if the treadmill is
unplugged. Do not touch components on the lower board. A charge can remain after
unplugging the power cord and turning off the treadmill.
1. Disconnect the external power source.
Turn the main power switch on the left side to the off (O) position.A.
Unplug the treadmill from the power outlet.B.
2. Remove the motor cover.
Using a Phillips screwdriver, loosen three screws on each motor cover side (left and right). See A.
Figure 2.
