Cybex Pro+ Treadmill Service Manual
Service
Page 4-39
ITEM QTY. PART NO. DESCRIPTION
105 2 PL-17686 Tab, Bookholder
106 1 HX-16931 Clamp, Cable, 5-16 dia Standard
107 1 AD-16559 PCA, Pro+, Lower Display, English
107 1 AD-16559-Q PCA, Pro+, Lower Display,
International
108 1 SK-17171 PCA, Pro+, Upper Display, English
108 1 AD-18199-Q PCA, Pro+, Upper Display,
International
110 1 AD-19366 PCA, CSAFE Port Board, W-TVS
111 1 EC-17763 PCA Salutron Serial Output
112 1 AW-17707 Cable, CHR to display with ferrite
113 1 AF-17684 Handrail, Weldment
116 2 HX-15499 Grip Handlebar
118 6 HS-10716 Screw 4-40 x 0.38 PNHD Phil
119 4 EH-00472 Wire Tie Ty-23M
120 1 FS-16841 Mount, E-stop Magnet
121 2 HS-16940 Screw, Sems 10-32 x 3/8”, PNHD
ext, BL ZN
122 1 FS-16990 Plate, Switch, Power On-Off
123 1 SW-10523 Switch, On-Off
124 12 HS-41187 Screw, 8/16 x 5/16”, Plastite
125 17 HS-15706 Screw, 8/16 x .50”, PNHD STL BLK
Phil
126 1 HX-17711 Plug, Hole Plastic 7-16 Black
127 1 HX-19040 Clamp, Cable, 3/4” Diameter
128 1 HX-17697 Tape, Double Sided, Die Cut, .062”,
Thick
129 1 HX-16842 Magnet, E-stop
130 2 AX-19669 Grip, Heartrate Grip, Top
131 2 AX-19670 Grip, Heartrate Grip, Bottom
132 2 PL-20360 Endcap, Heartrate Grip
133 4 HS-20306 Screw, 6 - 20 X 1.12”, PNHD PHIL
134 1 AX-16812 Power Factor Correction Assembly
135 1 AX-21397 Assembly, Deck Stiffener, Pivot, Left
136 1 AX-21396 Assembly, Deck Stiffener, Pivot,
Right
137 2 HS-19108 Screw, 5/16 - 18 X 34”, LG, HXHD,
Whiz-lock, GR5
138 1 FM-19439 Shaft, Deck Pivot
139 2 HN-20041 Nut, 1/4 - 20, Propeller, .305” OD
140 2 HW-20044 Washer, Belleville, 15 X 8.2 X
1.0 MM, .5MM Thick
141 2 HS-18358 Bolt, 5/16 - 18 X .1.25”, SCHD CAP,
BLK ZN
142 1 DE-19451 Decal, WEEE Symbol
143 2 DE-17714 Decal, Cybex, 13.8 X 2.2”
144 1 DE-16784 Decal, Side Stripe
145 2 DE-17713 Cybex Pro+ Decal for Side
Extrusions
146 2 HN-60064 Nut, Jam 3-8”-16 blk zn
147 1 EC-15004 Ferrite, Clamp-on, .40” ID
200 1 AF-20678 Bracket, SLANT Mount,TV Arm
201 1 CP-20665 Monitor, CYBEX, 15” SECAM/PAL
201 1 CP-20794 Monitor, CYBEX, 15” ASTC
202 1 HX-20032 Cap, Domed, Plastic
203 2 PL-20015 Cap, Black
204 3 FT-19980 Tube, Spacer, .375 Dia , .28” Wall
205 1 HS-20036 Screw, 5/16-18 x 1.50”, ScHd, Stl,
Zn
206 2 HS-41107 Bolt, 5/16-18 x 1.50”, Bh, SS, Bl
207 2 HX-20782 Bushing, T- Type,Rubber, Ring
Mount, Vibration Isolator
208 8 HW-20779 Washer, Flat, 1.44 x .325”, SS
209 6 HX-20778 Bushing,Rubber, Ring Mount,
Vibration Isolator
210 1 HW-53018 Washer, 5/16”, Split
ITEM QTY. PART NO. DESCRIPTION
211 4 HS-20731 Screw, M4x10 ScHd Stl, Blk
212 4 HW-21285 Washer, Lock, M4 Zn
213 4 HW-20214 Washer, Flat, M4
NS 1 AW-16561 Cable, Univ. Tread Display
NS 1 AW-16572 Jumper, Switch-Filter, White, US
NS 1 AW-16578 Jumper, Filter-cntl, White
NS 1 AW-16579 Jumper, Filter-cntl, Black
NS 1 AW-16638 Power Cord, 230 VAC, 50Hz
NS 1 AW-16639 Power Cord, 220 VAC, 60Hz
NS 1 AW-16640 Power Cord, 115 VAC, 60HZ
NS 1 AW-16938 Jumper, Switch-Filter, Black, US
NS 1 AW-17163 Jumper, Switch-Filter, Black, Intl.
NS 1 AW-17164 Jumper, Switch-Filter, White. Intl.
NS 1 AW-17694 Cable, Audio, 1/4” to 3.5mm, 18”
NS 1 AW-17694 Cable & Audio Jack 1/4 in to 3.5 mm
NS 1 AW-17706 Cable, Contact HR Grip
NS 1 AW-17732 Cable, 4” Ribbon C-SAFE
NS 1 AW-19117 Cable, 515T / 530T, A/V, I/O
NS 1 AW-19502 Cable, AV Keypad Extension
NS 1 AW-19502 Cable, Ribbon, AV Keypad
Extension
NS 1 AW-19523 Power Cord, 230 VAC, 50Hz, 13A,
UK
NS 1 AW-19648 Cable, Speed Sensor
NS 1 AW-20111 Cable E5, RJ45
NS 1 AX-16273 Clamp Assy, Handrail Ext.
NS 1 AX-16956 Kit, Install Hardware
NS 0 AX-17174 Handrail Extension Kit, Left Only -
Complete kit with instructions
NS 0 AX-17175 Handrail Extension Kit, Right Only
Complete kit with instructions
NS 0 AX-17217 Handrail Extension Kit, Left and
Right - Complete kit with instructions
NS 1 CN-17687 Adapter, 1/4” Plug to 1/8” Jack
NS 1 FT-16278 Handrail Extension, Spacer, Bottom
hardware
NS 1 HS-16921 Handrail Extension, Bolt, 5/8-11 x
4.75, Bottom hardware
NS 2 HS-16935 Handrail Extension, Screw, Set 1/2
13 x 1/2”, Top Hardware
NS 1 HX-00438 Allen Wrench, 3/16”
NS 2 HX-16852 Handrail Extension, Grip
NS 1 LT-03051 Sign, Facility Safety
NS 1 LT-17718 Poster, Assembly
NS 1 LT-21250 Product Registration Sheet
NS 1 LT-17730-X Owner’s Manual, Cybex Pro+*
NS 1 LT-17446 Warranty Sheet, Cybex Pro+, Pink
NS 1 SK-17827 Kit, Assembly, Contact Heart Rate
Grip, Pair
NS 1 SK-18554 Brush Kit, Pair, 110 or 220 VDC, w/
spring clips
