CY7C68013
Document #: 38-08012 Rev. *A Page 35 of 48
6.0 Absolute Maximum Ratings
Storage Temperature.................................................................................................................................... –65°C to +150°C
Ambient Temperature with Power Supplied........................................................................................................ 0°C to +70°C
Supply Voltage to Ground Potential..................................................................................................................–0.5V to +4.0V
DC Input Voltage to Any Input Pin ................................................................................................................................. 5.25V
DC Voltage Applied to Outputs in High Z State ...................................................................................... –0.5V to V
CC
+ 0.5V
Power Dissipation...................................................................................................................................................... 936 mW
Static Discharge Voltage............................................................................................................................................ > 2000V
Max Output Current, per I/O port.................................................................................................................................. 10 mA
Max Output Current, all five I/O ports (128- and 100-pin packages) ............................................................................ 50 mA
7.0 Operating Conditions
T
A
(Ambient Temperature Under Bias) ............................................................................................................... 0°C to +70°C
Supply Voltage..................................................................................................................................................+3.0V to +3.6V
Ground Voltage.................................................................................................................................................................... 0V
F
OSC
(Oscillator or Crystal Frequency)......................................................................................................24 MHz ± 100 ppm
..................................................................................................................................................................... Parallel Resonant
8.0 DC Characteristics
8.1 USB Transceiver
USB 2.0-compliant in full- and high-speed modes.
Table 8-1. DC Characteristics
Parameter Description Conditions Min. Typ. Max. Unit
V
CC
Supply Voltage 3.0 3.3 3.6 V
V
IH
Input HIGH Voltage 2 5.25 V
V
IL
Input LOW Voltage –0.5 0.8 V
I
I
Input Leakage Current 0< V
IN
< V
CC
±10 µA
V
OH
Output Voltage HIGH I
OUT
= 4 mA 2.4 V
V
OL
Output LOW Voltage I
OUT
= –4 mA 0.4 V
I
OH
Output Current HIGH 4mA
I
OL
Output Current LOW 4mA
C
IN
Input Pin Capacitance Except D+/D– 10 pF
D+/D– 15 pF
I
SUSP
Suspend Current Includes 1.5k internal pull-up 250 400 µA
I
CC
Supply Current 8051 running, connected to USB HS 200 260 mA
8051 running, connected to USB FS 90 150 mA
