D-Link DAP-1320 User Manual

12D-Link DAP-1320 User Manual
Section 3 - Conguration
6. If your wireless device supports WPS, click on Select this option if
your wireless device supports WPS (Wi-Fi Protected Setup). For
manual setup, skip to Step 8 on the next page.
Click Next to continue. You will see instructions on the screen that
say, Press the Push Button (physical or virtual) on the AP or Router...
5. Select your Language from the drop-down menu and click Next
to continue.
4. By default, Admin is the user name. Enter the Admin Password
(blank by default) and click Login.
Note: If this is your rst time logging into the DAP-1320, you will be
directed to the Setup Wizard automatically.

D-Link DAP-1320 Specifications

Wireless Standards and Antennas

wireless standards	IEEE 802.11n, IEEE 802.11g
antenna type	2 Internal Antennas

Weight and Dimensions

dimensions	1.89” x 1.65” x 2.11” (4.8 x 4.19 x 5.36 cm)
weight	0.152 lb (68.94g)
